Ubiquiti ER-6P PoE EdgeRouter with EdgeMAX Technology

Ubiquiti ER-6P PoE EdgeRouter with EdgeMAX Technology

The Ubiquiti ER-6P PoE EdgeRouter is a compact wired router made for small offices, retail branches, labs, and managed network deployments. It combines five Gigabit RJ45 ports, a 1G SFP uplink, and 24V passive PoE on five ports, therefore you can simplify cabling and reduce power adapters for compatible devices. Moreover, the metal enclosure and flexible mounting options suit professional network rooms and tidy installations.

Product Overview

This EdgeRouter 6 PoE model supports clean, structured networking where reliability matters. In addition, it includes an RJ45 serial management interface, which helps with controlled administration in professional environments. As a result, setup and maintenance can stay consistent across sites, especially when standard IT workflows are required.

Inside, the ER-6P includes 1GB DDR3 RAM plus onboard storage (4GB eMMC and 8MB SPI NOR). Moreover, it ships with an external 24V/2.5A AC/DC adapter for power. However, the PoE output is 24V passive, so you should only connect devices that explicitly support 24V passive PoE. Consequently, it’s a strong fit when you want power and routing in one compact unit.

Key Features

• (5) GbE RJ45 ports + (1) 1G SFP port → Therefore, you can connect copper endpoints and keep an uplink option for fiber or compatible transceivers.

• (5) 24V passive PoE ports → In addition, you can power compatible devices over Ethernet and reduce extra adapters.

• RJ45 serial management interface → Moreover, it supports practical, controlled access for authorized configuration.

• Metal enclosure → As a result, it suits professional installs where durability and neat cabling matter.

• Port LEDs for PoE and link/activity → Consequently, quick checks are easier during routine support.

• Factory reset button → However, it should be used only during approved recovery or reconfiguration.

• Wall or rack mounting support → Finally, mount on a wall or use the optional ER-RMKIT for rack placement.

Technical Specifications

• Brand: Ubiquiti

• Model: ER-6P (EdgeRouter 6 PoE)

• Product: Ubiquiti ER-6P PoE EdgeRouter

• Dimensions: 229 × 136.5 × 31.1 mm (9 × 5.4 × 1.2″)

• Weight: 730 g (1.6 lb)

• Enclosure material: Metal

• System memory: 1GB DDR3 RAM

• On-board storage: 4GB eMMC, 8MB SPI NOR

• Networking interfaces: (5) GbE RJ45 ports, (1) 1G SFP port

• Management interface: (1) RJ45 serial port

• PoE interface: (5) 24V Passive PoE ports (2-pair and 4-pair)

• Max PoE per port: 24W (24V, 1A, 4-pair) / 12W (24V, 0.5A, 2-pair)

• Power method: AC/DC power adapter, 24V, 2.5A (included)

• Power supply: External AC/DC adapter, 60W

• Supported voltage range: 16–30V DC

• Max power consumption: 16W (excluding PoE output)

• Operating temperature: -10 to 50°C (14 to 122°F)

• Operating humidity: 10 to 90% noncondensing

• Certifications: CE, FCC, IC

• NDAA compliant: Yes

• Warranty: To be confirmed
